Discover the superior quality and performance of the RTK Regeltechnik REact 30E-074 with actuator and valve. with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The REact 30E-074 with actuator and valve. is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of REact 30E-074 with actuator and valve. :
At Impexron GMBH , we offer the REact 30E-074 with actuator and valve. at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the REact 30E-074 with actuator and valve. ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | REact 30E-074 with actuator and valve. |
Internal code | IMP4011481 |
Technical specification | Control valve Motorized control valve - MV 5274 series in three-way form for mixing, with short B-flange Nominal size DN 25, nominal pressure PN 16 Housing material nodular cast EN-GJS-400-18-LT Flanges with sealing surface according to DIN Spindle seal: Bellows with safety stuffing box PTFE Characteristic curve / flow: linear / - Mixing cone, metallic sealing Kvs value = 9.2 m³ / h, stroke 15 mm Seat diameter 32 mm Surface treatment with zinc dust primer Max. permissible pressure according to DIN EN 1092 Max. permissible temperature TS 350 ° C Electric actuator - type REact 30E-074 Positioning force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm / s, stroke 15 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) |
