Discover the superior quality and performance of the ARI ARI-STEVI 440 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ARI-STEVI 440 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ARI-STEVI 440 :
At Impexron GMBH , we offer the ARI-STEVI 440 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ARI-STEVI 440 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ARI products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | ARI |
Product | ARI-STEVI 440 |
Description | Valve in continuous shape with flanges |
Internal code | IMP3998038 |
Technical specification | Figure 23.440 DN 25 ARI-STEVI 440 Straight type control valve with flanges EN-JS1049 DN 25 Data sheet:440001-1.pdf Operating manual:0040301000-1.pdf Discount group: I11 Nominal pressure: PN 25 Flange drilling: according to DIN PN25 Kvs value: 10 Characteristic curve: equal percent Spindle seal: EPDM Drive: DP32 Effectively (b.pneum.antr): Spring closes in case of air failure feathery. (bar) /stroke (mm): 0.80-2.40 stroke 20 mm Erford. Setting pressure (bar): 2.7 bar max. admissible Setting pressure (bar): 6 max. closing pressure (bar): 25 Distance column length: L1=188 mm Distance column spacing: 100 mm Coupling: M10 thread Positioner: EPS 15.2 Sipart PS2 Input signal: 4 - 20mA 2-wire Adjusted: 4 mA valve closed Inlet with ventilation air (bar): 6 bar Filter reduction station: 0.5 - 10 bar standard (Riegler) |
