Discover the superior quality and performance of the Demag ZBA 71 A 2 B003 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ZBA 71 A 2 B003 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ZBA 71 A 2 B003 :
At Impexron GMBH , we offer the ZBA 71 A 2 B003 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ZBA 71 A 2 B003 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Demag |
Product | ZBA 71 A 2 B003 |
Description | Engine |
Internal code | IMP4915849 |
Technical specification | The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Motor speed 2750 rpm Power 0.37 kW Operating time 60% Motor protection class IP 54 Ambient temperature -20... +60 °C Installation height ≤ 1000 m Design key ZBA 71 A 2 B003-H-1 Type H Terminal box position on the right, 1 Horizontal motor installation position Total net weight approx. 12 kg Electrical data: Supply voltage D/Y 230/400 V Line frequency 50 Hz Current D/Y 1.70/1.00 A Brake technical data: Braking torque 2.5 Nm Voltage 180 V DC Current 0.11 A with brake rectifier GE 400 V AC equipment: 2 temperature monitors for shutdown at 155 °C with phase insulation for inverter operation with sprocket for direct attachment to DRF200 i=43.70 Light fan disc Oiltight bearing plate selected ambient temperature: 60° C Warmth class F Warmth class F color scheme: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive |
