Discover the superior quality and performance of the Demag ZBA 100 B 4 B050 H 3 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ZBA 100 B 4 B050 H 3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ZBA 100 B 4 B050 H 3 :
At Impexron GMBH , we offer the ZBA 100 B 4 B050 H 3 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ZBA 100 B 4 B050 H 3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Demag |
Product | ZBA 100 B 4 B050 H 3 |
Description | cylinder rotor motor |
Internal code | IMP4943926 |
Technical specification | The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Motor speed 1700 rpm Power 3.60 kW Operating time 60% Motor protection class IP 54 Ambient temperature -20... +60 °C Installation height ≤ 1000 m Construction key ZBA 100 B 4 B050-H-3 Type H Terminal box layer on the left, 3 Horizontal motor installation position Electrical data: Supply voltage D/Y 250/440 V Line frequency 60 Hz Current D/Y 12.00/6.90 A Brake technical data: Braking torque 39.0 Nm Voltage 198 V DC Current 0.18 A with brake rectifier GE 440 V AC equipment: 3 cold conductors for shutdown at 160 °C with phase insulation for inverter operation D/Y motor circuit with sprocket for direct attachment to A50D i=41.70 Light fan disc selected ambient temperature: 60° C Warmth class F abnormal brake tension Noise-reduced design with factory certificate 2.1 in accordance with EN 10204 1x coloring: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive |
