Discover the superior quality and performance of the RTK Regeltechnik W.Nr. 110.020 / MV 5214 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The W.Nr. 110.020 / MV 5214 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of W.Nr. 110.020 / MV 5214 :
At Impexron GMBH , we offer the W.Nr. 110.020 / MV 5214 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the W.Nr. 110.020 / MV 5214 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | W.Nr. 110.020 / MV 5214 |
Description | motor control valve |
Internal code | IMP4893022 |
Technical specification | Motor control valve - MV 5214 series in continuous form nominal size DN 50, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 37 m³/h, stroke 30 mm Seat diameter 50 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-074 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor setting speed 0.74 mm/s, stroke 30 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms |
