Discover the superior quality and performance of the Verlinde VX5 1004 B2 - EUROCHAIN with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The VX5 1004 B2 - EUROCHAIN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of VX5 1004 B2 - EUROCHAIN :
At Impexron GMBH , we offer the VX5 1004 B2 - EUROCHAIN at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the VX5 1004 B2 - EUROCHAIN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Verlinde products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Verlinde |
| Product | VX5 1004 B2 - EUROCHAIN |
| Internal code | IMP4924010 |
| Technical specification | (Galvanized Chain) Rated capacity 1000 kg Height of lift 4 m Load chain Galvanized Reeving 02 Hoisting speed 4.8 / 1.2 m/min Hoisting motor power 0.86 KW Hoisting motor - nominal current 2.4/1.6 A Hoisting motor - starting current 7.2/2.35 A Hoist duty group M5 Hoist suspension Bracket long Trolley type Motor trolley Trolley flange width range 58-200 mm User girder flange width 200 mm Travel speed control Inverter two steps Travel speed high 37 m/min Travel speed low 10 m/min Trolley motor power 0.15 KW Trolley motor - nominal current 1.1 A Trolley motor - starting current 2.3 A Main voltage 460 V Phase count 3 Phases Frequency 60 Hz Control voltage 48 V Pendant cable length 3.5 m Chain bag Yes Mechanical overload device Friction torque limiter Standard temperature range -10°C to +40°C with rated load and speed (ED 60%, 300 start/hr) Hoisting limit switch Electrical upper & lower limit switch (2 steps) Paint 5 years guaranteed RAL 7021 Standard maximum humidity 90 % Control pendant Remco 4 button pendant with emergency stop Approx. hoist weight including options 58 kg C-dimension (headroom) 546 mm Overheating protection for hoisting motor Included Hoist Options: IP66 protection IP66 on hoist panel, hoisting motor, travelling motor Rain cover Yes Chain lubrication Grease Pendant protection IP65 Chain bag Flexible Trolley Options: Thermal protection for trolley Yes Trolley drive protection IP55 Documents: Number of documents in package 1 Language of documents English (EN) Document delivery Documents to be shipped with the material |
