Discover the superior quality and performance of the Verlinde VR16 3204 b2 0709P with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The VR16 3204 b2 0709P is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of VR16 3204 b2 0709P :
At Impexron GMBH , we offer the VR16 3204 b2 0709P at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the VR16 3204 b2 0709P ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Verlinde products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Verlinde |
| Product | VR16 3204 b2 0709P |
| Description | electric chain hoist with electric trolley |
| Internal code | IMP4816503 |
| Technical specification | Rated capacity 3200 kg Height of lift 6 m Load chain Galvanized Reeving 02 Hoisting speed 4 / 0.7 m/min Hoisting motor power 2.3 KW Hoisting motor - nominal current 5.7/2.7 A Hoisting motor - starting current 27/4.5 A Hoist duty group M5 Hoist suspension Rigid Trolley type Motor trolley Trolley flange width range 196-253 mm User girder flange width 253 mm Travel speed control Inverter two steps Travel speed high 20 m/min Travel speed low 5 m/min Trolley motor power 0.3 KW Trolley motor - nominal current 1.2 A Trolley motor - starting current 4.2 A Main voltage 400 V Phase count 3 Phases Frequency 50 Hz Control voltage 48 V Pendant cable length 5.5 m Chain bag Yes Protection class IP55 Mechanical overload device Friction torque limiter Standard temperature range -10°C to +40°C with rated load and speed Hoisting limit switch Electrical upper & lower limit switch (2 steps) Paint 5 years guaranteed RAL 7021 Standard maximum humidity 90 % Control pendant Schneider 4 button pendant with emergency stop Approximate hoist weight 169 kg C-dimension (headroom) 678 mm Overheating protection for hoisting motor Included Chain lubrication Grease Selected pendant options Schneider pendant Trolley Options Thermal protection for trolley Yes Number of documents in package 1 Language of documents English (EN) Document delivery Documents to be shipped with the material |
