Discover the superior quality and performance of the Proval V1010050PNM-00382 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The V1010050PNM-00382 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of V1010050PNM-00382 :
At Impexron GMBH , we offer the V1010050PNM-00382 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the V1010050PNM-00382 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Proval products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Proval |
Product | V1010050PNM-00382 |
Description | V101 DN50 PNEUMATIC ACTUATED WAFER TYPE BUTTERFLY VALVE |
Internal code | IMP4997039 |
Technical specification | GTIP code: 8481.80.85.00.00 Product Code V1010050B0BRE0P1K09C103AJS0-A210DG052WSK09GG14A6NYC00000001 Dimension (DN): 050 | Body: GGG40 RAL9005 Black | Disc: GGG40 (Rilsan Coated) | Gasket: EPDM (-30/+130ºC) | Shaft Material: AISI420 1.4021 | Shaft Dimension: PS-9x9 H:17.5 | Top Flange: F05 | Pressure Class: PN16 | Flange Fit: EN1092 PN10/16 - ANSI B16.5 Class 150 | L Size: EN558 Series 20 | Option: Standard | Extension: None | Control: A210-On/Off Pneumatic Actuator 0-90° | Actuator - Configuration: DA-Double Acting | Air Supply: 6.0 | Model: A210 - PA052 | Direction of rotation: CCW - Clockwise Reverse | Indicator: Standard | Shaft Joint Size: PS-9x9 D:14 | Shaft Material: Alloy Steel (Galvanized Coated) | Air Port: G1/4 | Flange Connection: F03/F05 | O-Ring: NBR | Body Material/Finish: Black Anodized Coated | Cover Material/Coating: Alu Enj./ Epoxy RAL.2004 Orange Glossy | |
