Discover the superior quality and performance of the Calectro UG-3-A40-VR06 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The UG-3-A40-VR06 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of UG-3-A40-VR06 :
At Impexron GMBH , we offer the UG-3-A40-VR06 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the UG-3-A40-VR06 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Calectro products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Calectro |
| Product | UG-3-A40-VR06 |
| Description | Channel smoke switch |
| Internal code | IMP4476297 |
| Custom code | 85311030 |
| Technical specification | Calectro air duct smoke switch 24 V AC/DC The Uniguard smoke detector was developed and combined to detect smoke in ventilation ducts a smoke detector with an adapter system, whereby the pipe and housing are specially designed for optimal airflow were designed by the smoke detector. The Uniguard smoke detector has an integrated Alarm relay for controlling ventilation flaps, stopping fans and activating acoustic and visual alarms, etc. The integrated service alarm relay informs you about upcoming Maintenance work before false alarms occur. The smoke detector has an intelligent control and monitoring circuit. This circuit adjusts the sensitivity to achieve the optimal enable the smoke detector to function over its entire service life. When the the monitoring circuit can no longer compensate for contamination, a service alarm is triggered is spent. Uniguard Superflow has four pre-assembled cable entries with IP67 approval with automatic pull load anchoring for cable diameters of 4-11 mm, type Klikseal. The bayonet mount of the smoke detector makes it easy to install and remove. TECHNICAL DATA Power supply: 24 V AC/DC ± 10% Max. power consumption: 165 mA Operating temperature: -10 °C to +50 °C Maximum humidity: 99% RH Channel ventilation performance range: approx. 0.2 to 20 m/s approvals UG-3-A4O: VdS (Germany) detector head: EN-54-7 Relay output: potential-free Smoke alarm relay: Two changeover contacts 250 V, 5 A Service alarm: One changeover contact 250 V, 5 A Degree of protection: IP54 |
