Discover the superior quality and performance of the Warex type DKZ 110
The type DKZ 110
Key Features of type DKZ 110
At Impexron GMBH , we offer the type DKZ 110
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the type DKZ 110
Important Notice: While we supply Warex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Warex |
Product | type DKZ 110 <APS> DN 80 |
Description | butterfly valve |
Internal code | IMP4793712 |
Custom code | 84818085 |
Technical specification | based on order : 168396 / 2021 for medium: bulk characteristics: chemical not aggressive, not sticky working pressure: pressureless max. allowable working pressure: 0,5 bar (Ps) MAWP (note: MAWP = design pressure) max. allowable working temperature: 0 °C ... + 60 °C (Ts) MAWT ambient temp.: 0 °C ... + 50 °C (Ta) Ex-protection: No requirement Rating of butterfly-valves according PED/2014/68/EU, diagram 9 Certified module A2 The butterfly-valves are not subject to this conformity assessment test pressure: design pressure x 1,1 bar for tightness WX2000 face to face 39 mm for mounting between flanges, drilled according to EN 1092, PN 10 body of Silumin disc of stainless steel 1.4408 - with enlarged gap - shaft of stainless steel stainless steel 1.4057 or equivalent shaft sealing with o-rings bearing bush of brass inflatable sealing element of Buna CB black replaceable in the housing additional attachments: pneumatic actuator AT 30 DR double acting air supply necessary 6,0 bar limit switch box with 2 micro switches Crouzet 83.161.301W2 10A, 300V AC mounted in TCR-housing 144/64/70 transparent cover of makrolon wired on terminal for disc position "open-closed" incl. mounting bracket |
