Discover the superior quality and performance of the Boll Kirch Typ: 6.21.1 Gr 05 DN 50 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Typ: 6.21.1 Gr 05 DN 50 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Typ: 6.21.1 Gr 05 DN 50 :
At Impexron GMBH , we offer the Typ: 6.21.1 Gr 05 DN 50 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the Typ: 6.21.1 Gr 05 DN 50 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | Typ: 6.21.1 Gr 05 DN 50 |
| Internal code | IMP4190033 |
| Technical specification | Commodity code: 842199 Filter type: 6.21.1 Gr: 05 Connection diameter: DN 50 Flanges to: WN165, square flanges Dimension sheet: Z144864 — OPERATING CONDITIONS — Fluid to be filtered: fuel fluid group according to PED: 1 Fluidart according to PED: liquid Maximum allowable pressure: 10.00 bar allowance Operating temperature min: 0,00 °C allowance Operating temperature max: 150.00 °C — BACKWASH Backwash medium: Own medium Flushing volume: 0.20 l/h at 5.00 bar Rinsing time: 1 s Control medium: Air 4-7 bar ISO8573- 1:2010 (7/4/4) Operating voltage: 3 ph 400 volts Frequency: 50 Hz Control voltage: 110 volts Control: Type 2300 (supplied loose) : Z46611, ID 4302300 — CONSTRUCTION/ACCEPTANCE — Design and layout: PED2014/68/EU AD-2000 Art. 4, para. 3 Container volume: 6.00 litres Empty weight: 75 kg Pressure test according to: Boll & Kirch with certificate Material: EN 10204/3.1 — MATERIALS — Filter housing made of: EN-GJS-400-15 Tap chick switch for bypass filter: EN-GJS-400-15 Gasket off: Viton GF-S — FILTER ELEMENTS — Item Type: Multi Segment Element Number of filter elements: 1 Number of filter elements per chamber: 1 no. of filter chambers: 1 Cloth of: 1.4401 Tissue Number: 294/31 Nom. Filter fineness: 20 μm Screening area in operation: 2000 cm² Total screening area: 2000 cm² Sieve insert for bypass filter: Star sieve element Filter fineness bypass filter: 34 μm Screen area bypass filter: 5260 cm² Filtration Absolut Automat: 34 μm Filtration Absolute Bypass: 37 μm — ACCESSORIES — Attached differential pressure indicator: 4.36.2 (optic+electrical) Differential pressure gauge sealant: Viton GF-S Backflushing differential pressure settings: 0.90 bar, alarm 1.20 bar Opposites. Screws and gaskets: included Other accessories: DDA with stopcocks : Filter with lid protection : (BYPASS) — CORROSION PROTECTION — Exterior base coat: 2K-Ep RAL 5005 Inner Preservation: Shell Tellus S2 M 32 — LABELLING — Operation/Factory plate: German/English CE marking according to: - Machinery Directive 2006/42/EC: CE |
