Discover the superior quality and performance of the Rittal SV 9342.311 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SV 9342.311 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SV 9342.311 :
At Impexron GMBH , we offer the SV 9342.311 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the SV 9342.311 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rittal products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Rittal |
Product | SV 9342.311 |
Description | terminal block |
Internal code | IMP4977924 |
Custom code | 85369010 |
Technical specification | Suitable for 12 x 5 to 30 x 10 mm busbars and PLS 800/1600. Chassis: polyamide Cover: ABS Fire behavior in accordance with UL 94-V0 RAL 7035 3 clamps including cover Clamping space for laminated copper bars with 5 mm bar thickness (W x H) 33 x 26 mm Clamping space for laminated copper bars with 10 mm bar thickness (W x H) 33 x 22 mm cable outlet top/bottom Rated current max. 800 A Electrical values UL (SCCR) 65 kA - 480 V, circuit breaker max. 600 A, DIVQ/7 65 kA - 600 V, Fuse Class L max. 800 A, JDDZ/7 note In an overvoltage category III, a rated operating voltage of 1000 V (AC) is achieved. When using the clamp on 2-pole busbar systems (SV 9340.040), the clamp must be rotated 180° to connect to the PE busbar. Width:50mm height: 88 mm Connection of round conductors, fine-stranded with core sleeve 95 ‐ 185 mm² Connection of round conductors, multi-wire 95 ‐ 300 mm² Packing unit 3 pieces |
