Discover the superior quality and performance of the Nord SK1SIS50VF-IEC71-71SP/4 TF 175E with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SK1SIS50VF-IEC71-71SP/4 TF 175E is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SK1SIS50VF-IEC71-71SP/4 TF 175E :
At Impexron GMBH , we offer the SK1SIS50VF-IEC71-71SP/4 TF 175E at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the SK1SIS50VF-IEC71-71SP/4 TF 175E ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nord products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Nord |
| Product | SK1SIS50VF-IEC71-71SP/4 TF 175E |
| Description | IEC motor worm gear |
| Internal code | IMP4803842 |
| Technical specification | Design: as already delivered with serial number 203448269-100 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Product name worm gear IEC motor Motor speed 1.415 rpm Translation 80.00 Output speed 18,000 rpm Operating factor 1.10 Output torque M2 (Nm) 62.60 Power (kW) 0.250 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Current Rating 1 (AMP) 1.21 Nominal current 2 (AMP) 0.70 Cosine 1 0.71 Universal gearbox design Housing type B5 solid shaft flange IEC71 B14 C105 mounting cylinder Position of the output shaft shaft at B (VB) Wave size 20X40 Flange type II-angular profile with inner recess Flange diameter (mm) 125 Flange bracket flange at B (FB) Aluminum flange material Venting Without venting Thermal motor protection cold conductor, 3x155°C Star circuit type Lubricant type Synth. ISO VG 680 oil Lubricant supplier Klüber CLP PG 680 oil grade Lubricant quantity (l) 0.095 Painting instructions Without painting CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Lot part 2. Transmission type plate 2nd motor nameplate Type frequency inverter/starter SK 175E-301-340-B-ASI Mat. -No. Inverter/Starter 275229360 Version/data PTC input 1 brake control Soft start functionality reversing functionality Diagnostic interface RS232 RJ12 Status LEDs setpoint potentiometer AS-interface on board 2x Dig In, 2x Dig Out Ext. 24VDC power supply Rated power FU (kW) 3,000 Power rating FU (HP) 4,000 FU: input voltage 3AC 200-500V, + -10%, 47-63Hz Output current (A) 7.5 Protection class inverter/starter IP55 (standard) Location frequency inverter/starter 1 TI SK TIE4-M12-ASI signal connector SK TIE4-M12-INI DIN 1 SK TIE4-M12-INI DIN 2 SK TIE4-HAN10E-M2B-LE power input Pos. M12-ASI 4R Item M12-INI DIN 1.4L Item M12-INI DIN 2 5L Pos. HAN10E-MXB-LE 3L FU: UL approval Yes |
