Discover the superior quality and performance of the Lubbering SH500-LR330-S90-A1SS with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SH500-LR330-S90-A1SS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SH500-LR330-S90-A1SS :
At Impexron GMBH , we offer the SH500-LR330-S90-A1SS at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the SH500-LR330-S90-A1SS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Lubbering products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Lubbering |
Product | SH500-LR330-S90-A1SS |
Description | Screw system |
Internal code | IMP4039956 |
Custom code | 84671190 |
Technical specification | Flat output Basic-Line 13-52-12-S Item no .: 80521202 technical features: Open type Max. Wrench size 24 mm Max. Output torque 55 Nm Max. Drive torque 73 Nm Efficiency 0.75 Transmission ratio 1 Blade thickness 12 mm Center distance 49.23 mm Radius 32 mm Opening 16 mm Head dimension 20.1 mm Gear stage 2 Width at the output 59 mm Projection length 18 mm Molykote BR2 plus lubricant Output gear HEX19 Item number: 70954094 technical features: Output profile HEX Nominal size output 19 mm Profile depth 7.6 Length 39 mm External length 27 mm Cleared profile no Opening width 16 mm Nut holder wheel without Installation direction below adapter L.SP3 connect D-2026 technical features: Tool manufacturer AtlasCopco Key figure drive 2026 Adapter interface D Adjustment type adjustable Connection thread M39x1-LH Length 16 mm Transmission ratio 1 Attention: In case of an order we need the current angle head type WK03G with external thread M39x1 - left! Reaction support Item no .: SH500-LR330-S90-A13S Tool technical features: Tool manufacturer Desoutter Max. Torque 50 Nm Max. Speed 330 Pneumatic energy Item number manufacturer 2051474734 Profile output sd Nominal size output WK 1/2 " Weight 2.2 kg Running in of the flat output with Certificate in work direction |
