Discover the superior quality and performance of the Steimel ASF3-50RD-170039R with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ASF3-50RD-170039R is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ASF3-50RD-170039R :
At Impexron GMBH , we offer the ASF3-50RD-170039R at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ASF3-50RD-170039R ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Steimel |
Product | ASF3-50RD-170039R |
Description | pump unit |
Internal code | IMP4533333 |
Custom code | 84136039 |
Technical specification | Gear pump unit: SF 3/50 RD - VLFM Item no.: ASF3-50RD-170039R Dimension sheet: DPA053D-112LFM-R31 Spare parts list: DET053050RD-165R Suction and pressure connection: SAE 1 1/2 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., helical gear Storage: multi-layer Shaft seal: radial shaft seal elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 70.8/84.9 l/min pressure: 5 bar Speed: 1450/1740 rpm pressure relief valve Setting range: 2-18 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA055-1928-301 Bellhousing with foot: BLF053250128LA21 three-phase motor: LDM112-04-903 (Birkenbeul) Engine data: Power 1/2:4.0 /4.6 kW Speed 1/2:1500 /1800 rpm Voltage 1:230/400 volts at 50 Hz Voltage 2:265/460 volts at 60 Hz Efficiency class: IE3 Additional plate (without IE3) for: Voltage: 220-240/380-420 volts at 50/60 Hz : 250-280/440-480 volts at 60 Hz Degree of protection: IP 55 Insulation class: F Design: B 5 aggregate paint: primed HDO058 - green Type plate: ETY924-D-E—PE02 |
