Discover the superior quality and performance of the Aviteq SAE-GS33-2 380..420V 50HZ 25A IP00 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SAE-GS33-2 380..420V 50HZ 25A IP00 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SAE-GS33-2 380..420V 50HZ 25A IP00 :
At Impexron GMBH , we offer the SAE-GS33-2 380..420V 50HZ 25A IP00 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the SAE-GS33-2 380..420V 50HZ 25A IP00 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Aviteq products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Aviteq |
| Product | SAE-GS33-2 380..420V 50HZ 25A IP00 |
| Internal code | IMP4807206 |
| Custom code | 85365003 |
| Technical specification | 31996 SAE-GS33-2 380.. 420V 50HZ 25A IP00 CONTROL Drawing number 00907071 200 x 230 x 140 mm (HxWxD) Dimensions VIBTRONIC® -S control for connecting AVITEQ vibrating conveyors. The swing width of the conveyor can be continuously adjusted on the connecting device. Output adjustment range of close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) tested in accordance with the currently valid EC Directive. As network protection, we recommend protection in accordance with the rated current of connected magnetic vibrator (slow safety). Vibration rate SA.. 33.. 2,000 min-1 Display Seven LEDs show the operating status version for installation in central control stations, power cable without incl. control potentiometer set Thyristor protection, via safety fuse (super-flexible) Network fluctuation compensation ± 10%, the oscillation range remains constant Network tolerance, allowable voltage ± 10% Frequency ± 0.5% Oscillation range change proportional to setpoint Switch activation (permanent contact, potential-free) or voltage signal +24 V (DC) or Optocoupler Inputs external control variables 0.. 10 V (DC), 0/4.. 20 mA (DC) Sensor input for AViTEQ PA or PAL vibration sensor Remote monitoring outputs, relay output protective function When used on magnetic vibrators with an integrated PAL sensor Version SA.. -2 MV-... P (8V) Version SA.. -2V MVE33-1, MVF33-1, MVF33-2, MVG33-1 (P), MVH33-1 (P) (10V) Voltage and oscillation range control with impact monitoring When used with external PA vibration sensor Version SA.. 2S1 useful range control Magnetic Vibrator Temperature Switch Monitoring TXAE additional board required when used with multiple drives (version.. - 2X) 1-fold documentation, German |
