Discover the superior quality and performance of the ZANDER AACHEN 472851 / Minos SD1K with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 472851 / Minos SD1K is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 472851 / Minos SD1K :
At Impexron GMBH , we offer the 472851 / Minos SD1K at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 472851 / Minos SD1K ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ZANDER AACHEN products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | ZANDER AACHEN |
Product | 472851 / Minos SD1K |
Description | Ultra-slim coupling relay |
Internal code | IMP4722607 |
Technical specification | Safety function Safe coupling relay, combustion systems in continuous operation, stop category 0 Certified according to EN ISO 13849-1; IEC 62061; IEC 61508; EN 50156-1; EN 746-2; IEC 61511-1; EN 60204-1 PL; Cat.; SILCL (EN ISO 13849-1; EN 62061) PL e; SILCL 3; Cat. 4 CE, TUV approvals Operating voltage UB: DC 24 V (+/- 10%) Power consumption 1.5 W (module activated. No load) Repatriation circuit Switching capacity safe relay contact AC-15:5A, AC 230 V DC 13:4 A, DC 24 V (see “Derating” in the operating instructions) Switching capacity signal output C1 max. 100 mA Max. switch-on delay < 20 ms Relapse delay < 20 ms Ambient temperature -15 °C to 55 °C (see “Derating” in operating instructions) Protection class IP20 35 mm DIN rail assembly Dimensions 6.8 x 93.1 x 102.5 mm |
