Discover the superior quality and performance of the Aviteq 32005 - SAE-GS60-2 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 32005 - SAE-GS60-2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 32005 - SAE-GS60-2 :
At Impexron GMBH , we offer the 32005 - SAE-GS60-2 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 32005 - SAE-GS60-2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Aviteq products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Aviteq |
| Product | 32005 - SAE-GS60-2 |
| Description | CONTROLLER |
| Internal code | IMP1021857 |
| Weight | 1 |
| Custom code | 85365003 |
| Technical specification | 440.. 480V 60HZ 25A IP00 Dimensions 200 x 230 x 140 mm (HxWxD) VIBTRONIC® -S controller for connecting AVITEQ vibrating conveyors. The swing width of the conveyor can be adjusted continuously on the connection device become. Delivery rate adjustment range from close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) in accordance with the applicable EC Directive checked. As network protection, we recommend protection in accordance with the rated current of connected magnetic vibrator (sluggish fuse). Vibration rate SA.. 60.. 3,600 min-1 Display Seven LEDs show the operating status version for installation in central control stations, power cable without incl. control potentiometer set Thyristor protection, via fuse (superflink) Network fluctuation compensation ± 10%, the oscillation width remains constant Network tolerance, allowable voltage ± 10% Frequency ± 0.5% Proportional change in the setpoint range Switch release (continuous contact, potential-free) or voltage signal +24 V (DC) or optocoupler Inputs to external external control variables 0.. 10 V (DC), 0/4.. 20 mA (DC) Sensor input for AViTEQ PA or PAL vibration sensor Remote monitoring outputs, relay output protective function When used on magnetic vibrators with an integrated PAL sensor Version SA.. -2 MV-... P (8V) Voltage and frequency control with impact monitoring When used with an external PA vibration sensor Version SA.. 2S1 payload control Magnetic Vibrator Temperature Switch Monitoring Additional TXAE board required when operating with multiple drives (version.. - 2X) |
