Discover the superior quality and performance of the Rexroth R165379420 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The R165379420 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of R165379420 :
At Impexron GMBH , we offer the R165379420 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the R165379420 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rexroth products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Rexroth |
| Product | R165379420 |
| Description | BALL RUNNER BLOCK CARBON STEEL |
| Internal code | IMP3312179 |
| Weight | 1 |
| Technical specification | Runner block or guide rail Runner block Linear guide type Ball rail system Nominal size 30 Format FLS - flanged, long, standard height Ball chain Without ball chain (standard) Material (profiled rail systems) Carbon steel Preload class C0 – Without preload (clearance) Accuracy class N – Standard Self-aligning for compensation of misalignments Without self-alignment Width of runner block [mm] 90 Length of runner block [mm] 119.7 Height of runner block [mm] 35.35 Height of runner block with guide rail [mm] 42 Lubrication With initial lubrication and preservation Dynamic load capacity C [N] 46000 Footnote dynamic load capacity C Determination of the dynamic load capacities and load moments is based on a 100 000 m travel as per DIN ISO 14728-1. Often only 50 000 m are actually stipulated. For comparison: Multiply values C, Mt and ML from the table by 1.26. Dynamic torsional moment load capacity Mt [Nm] 800 Dynamic torsional moment load capacity Mt footnote Determination of the dynamic load capacities and load moments is based on a 100 000 m travel as per DIN ISO 14728-1. Often only 50 000 m are actually stipulated. For comparison: Multiply values C, Mt and ML from the table by 1.26. Dynamic longitudinal moment load capacity ML [Nm] 740 Dynamic longitudinal moment load capacity ML footnote Determination of the dynamic load capacities and load moments is based on a 100 000 m travel as per DIN ISO 14728-1. Often only 50 000 m are actually stipulated. For comparison: Multiply values C, Mt and ML from the table by 1.26. Static longitudinal moment load capacity ML0 [Nm] 1080 Static torsional moment load capacity Mt0 [Nm] 1160 Max. acceleration amax [m/s²] 500 Footnote amax If F<sub>comb</sub>◡<gt/> 2.8 • F<sub>pr</sub> : a<sub>max</sub> = 50 m/s<sup>2</sup> Maximum permissible linear speed vmax [m/s] 5 Seal SS – Standard seal Static load rating C0 [N] 66900 Mass m [kg] 1.5 Permissible ambient temperature -10 °C ... +80 °C Footnote permissible ambient temperature (min ... max) Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. Friction coefficient μ 0,002 ... 0,003 Footnote friction coefficient μ Without friction of seal Permissible ambient temperature (min) [°C] <prefix>-</prefix>10<suffix></suffix> Permissible ambient temperature (max) [°C] <prefix>+</prefix>80<suffix></suffix> Friction coefficient μ min. 0.002 Friction coefficient μ max. 0.003 Weight [kg] 1.56 Size A (profiled rail systems) [mm] 90 Size A1 (profiled rail systems) [mm] 45 Size A2 (profiled rail systems) [mm] 28 Size A3 (profiled rail systems) [mm] 31 Size B (profiled rail systems) [mm] 119.7 Size B with tolerance (profiled rail systems) 119,7 mm +0,5 Size B1 (profiled rail systems) [mm] 89.4 Size B1 (linear bushing) [mm] 89.4 Size E1 (profiled rail systems) [mm] 72 Size E2 (profiled rail systems) [mm] 52 Size E3 (profiled rail systems) [mm] 44 Size E8 (profiled rail systems) [mm] 48.4 Size E9 (profiled rail systems) [mm] 14.6 Size H (profiled rail system) [mm] 42 Size H1 (profiled rail systems) 35.35 Size H2 with cover strip (profiled rail systems) [mm] 28.55 Size H2 with cover strip (profiled rail systems) [mm] 28.35 Size K1 (profiled rail systems) [mm] 25 Size K2 (profiled rail systems) [mm] 26.7 Size K3 (profiled rail systems) [mm] 6.05 Size K4 (profiled rail systems) [mm] 6.05 Size N1 (profiled rail systems) [mm] 11 Size N2 (profiled rail systems) [mm] 7.9 Size N6 (profiled rail systems) [mm] 17 Size N6 with tolerance (profiled rail systems) 17 mm ±0,5 Size S1 (profiled rail systems) [mm] 8.5 Size S2 (profiled rail systems) M10 Size S5 (profiled rail system) [mm] 9 Size S9 thread diameter x lead with (profiled rail systems) M3x5 Size S9 thread diameter x lead with tolerance (profiled rail systems) M3x5 Size T (profiled rail systems) [mm] 80 Size T1 min (profiled rail systems) [mm] 16 Size V1 [mm] 7 |
