Discover the superior quality and performance of the S+S REGELTECHNIK Premasgard 2125 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Premasgard 2125 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Premasgard 2125 :
At Impexron GMBH , we offer the Premasgard 2125 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the Premasgard 2125 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply S+S REGELTECHNIK products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | S+S REGELTECHNIK |
| Product | Premasgard 2125 |
| Description | Pressure, differential pressure and volume flow transducers |
| Internal code | IMP5009096 |
| Technical specification | power supply 24 V AC/DC (± 10%) power consumption < 1 W at 24 V DC; < 2 VA at 24 V AC Burden Ra (ohms) = 25... 450 ohms for I variant load resistance RL > 25 kOhm for U variant output switchable 0 -10 V/ 4... 20 mA (via DIP switch) circuit type 3-wire connection measurement function differential pressure, volume flow (radiated output signal) power consumption < 45 mA Measurement ranges Multi-range switching with 8 switchable measurement ranges media temperature —20... +50 °C (temperature-compensated 0... +50 °C) Pressure connection with connector for pressure hose Ø 6 mm Pressure range ±5000Pa Type of printing differential pressure Zero-point offset ± 5% measurement range Over -/low pressure ± 50 kPa Medium clean air and non-aggressive, non-combustible gases signal filtering switchable 1 s/ 10 s (via DIP switch) electrical connection 0.14 - 1.5 mm², via screw terminals cable fitting M 16 x 1.5; with strain relief, replaceable max. inner diameter 10.4 mm Long-term stability ± 1% per year hysteresis 0.3% EW precision (5000 Pa): typically ± 35 Pa at +25 °C compared to calibrated reference device parts in contact with media brass, Ni, Duroplast, Si, epoxy, RTV, BSG, UV silicone gel Pressure accuracy ± 35 Pa Temperature drift ± 0.1% per °C EW linearity < ± 1% EW Humidity < 95% RH, non-condensing air Pressure measurement range 0... +1000 Pa/-1000... +1000 Pa 0... +2000 Pa/-2000... +2000 Pa 0... +3000 Pa/-3000... +3000 Pa 0... +5000 Pa/-5000... +5000 Pa protection class III (according to EN 60 730) Protection class IP 67 (according to EN 60 529) housing tested, TÜV SÜD, report no. 713139052 (Tyr 1) cable connection plastic cable screw (M 16 x 1.5; with strain relief, replaceable, inner diameter 10.4 mm) or M12 connectors in accordance with DIN EN 61076-2-101 (optional on request) housings made of plastic, UV-resistant, Material polyamide, 30% glass ball reinforced, color traffic white (similar to RAL 9016), with snap-on lid Case dimensions 72 x 64 x 37.8mm (Tyr 1) standards CE compliance, electromagnetic compatibility in accordance with EN 61326, according to EMC Directive 2014/ 30/EU |
