Discover the superior quality and performance of the United Electric Controls P/N: J120-193-M201-M550 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N: J120-193-M201-M550 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N: J120-193-M201-M550 :
At Impexron GMBH , we offer the P/N: J120-193-M201-M550 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the P/N: J120-193-M201-M550 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply United Electric Controls products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | United Electric Controls |
Product | P/N: J120-193-M201-M550 |
Description | Safety pressure switch 120-Series |
Internal code | IMP5054909 |
Technical specification | A00010172 Switch point setting: internal Switch point adjustable in the range: 20.0 psi... 500.0 psi/1.4 bar... 34.5 bar Switch point hysteresis: 4.0 psi... 45.0 psi/0.3 bar... 3.1 bar Maximum working pressure: 1500 psi/103.4 bar Maximum overpressure: 2500 psi/172.7 bar Process connection: 1/2" NPT (inner) made of stainless steel 316 Sensor: Welded 316 stainless steel membrane Notes: large 0.72” Orifice for clean-out purposes. NACE MR0175 compliant with M401 option Housing: Die cast aluminum, epoxy powder coated; Gasketed; cover lock; internal set point lock; aluminum nameplate; protection class NEMA4X/IP66 Switch: 1 SPDT Switching capacity: 15A 125/250/480 VAC resistive (default), 2A @ 30 VDC, 1A @ 48 VDC, 0.5A @ 125 VDC Electrical connection: two 3/4" NPT E/C; terminal Block standard options M201: Factory switch point setting of a Switch; specify pressure and rising/falling! M550: oxygen-purified according to ASTM G93, Type I detection, tests 1 to 3 XY630: Distributorcode Dangerous goods for air and sea freight: No |
