Discover the superior quality and performance of the RTK Regeltechnik PV6211K with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV6211K is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV6211K :
At Impexron GMBH , we offer the PV6211K at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the PV6211K ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | PV6211K |
Description | pneumatic control valve |
Internal code | IMP4709559 |
Technical specification | Replacement for W.No. 12112117/010 in straight form Nominal diameter DN 25, nominal pressure PN 25 Housing material Ductile iron EN-GJS-400-18-LT flanges with groove in accordance with DIN 2512 Spindle sealing: Non-ferrous chloroprene roof collars Curve/Anström.: equal percent/below the cone parabolic cone, soft-sealing Kvs value = 2.5 m³/h, stroke 25 mm seat diameter 12 mm Spindle heating: heating cartridge 1 x 10 W, 24 V UC GEHOPON-EX RAL 7001 special paint (silver grey) with certificate in accordance with EN 10204-2.2 max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 100 °C Valve in accordance with DIN EN 12 284 Tightness test in accordance with DIN EN 12 266-1 Pneumatic actuator - type ST 6135.B6-6G Inlet air pressure max. 6 bar Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: Gate A, mixing valve: Gate B) additional equipment: - Electric tire. Position controller, type SR 6136 (SIPART PS2) 2/3/4 wire connection Input 4.. 20 mA at 0% input, valve closed - 3/2-way solenoid valve, G 1/4 connection to 24 V DC |
