Discover the superior quality and performance of the Steimel SF 6/180 RD - LF with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SF 6/180 RD - LF is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SF 6/180 RD - LF :
At Impexron GMBH , we offer the SF 6/180 RD - LF at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the SF 6/180 RD - LF ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Steimel |
Product | SF 6/180 RD - LF |
Description | Gear pump |
Internal code | IMP4026548 |
Technical specification | P-SF6/180RD-LF, gear pump, 2-16 bar suitable for motor NEMA -256 TD, motor mounting with M20 Gear pump : SF 6/180 RD - LF Article no. : PSF6-180RD201115R Dimension sheet : DPP056-201115R Parts List : DET056180RD--165R Suction and discharge connection : SAE 2 ½ Housing parts : EN-GJL-250 (GG-25) Waves : 16 Mn Cr S 5, egh. gears, noise-optimized : EN-GJS-400-15 (GGG-40), ionitrided helical Storage : Multilayer MD Shaft seal : Radial shaft seal Elastomers : FKM Pumping medium : lubricating oil Viscosity : 50-5000 cSt. Temperature : 10-60°C Flow rate: approx. 210 l/min Pressure : 5 bars Speed : 1200 rpm pressure relief valve Setting range : 2-16 bar Opening pressure : 8 bar Direction of rotation : right Trial run : yes, with HLPD 46 Coupling : BKUA080-2441-302 Bellhousing with foot : BLF056355185LA11, Motor mounting thread M20! Engine mounting bolts : 4 pcs IBO20X045 loose in Pump carrier screwed in suitable for: Three-phase motor : NEMA 256 TD Power : 10 HP Design : D-flange, similar to IM B5 Coating : primed HDO058 - green Nameplate : ETY924-D-E--PE01 |
