Discover the superior quality and performance of the RTK Regeltechnik MV 5324 DN100 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MV 5324 DN100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MV 5324 DN100 :
At Impexron GMBH , we offer the MV 5324 DN100 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the MV 5324 DN100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | MV 5324 DN100 |
Description | motor control valve |
Internal code | IMP4839271 |
Technical specification | in three-way form for mixing Nominal diameter DN 100, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic curve/flow: linear/- mixed cone, metallically sealing Kvs value = 148 m³/h, stroke 30 mm seat diameter 100 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) Maximum allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 60E-045 Actuating force 6 kN, including manual adjustment AC motor 230 V, 50/60 Hz Operating speed 0.45 mm/s, stroke 30 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) - digital positioner, type rePos with display input signal: 4.. 20 mA Feedback signal: 4.. 20 mA Direction of action: at 0% input gate B closed Drive spindle extended at 0% input - Potentiometer 1000 ohms |
