Discover the superior quality and performance of the Vega MT31.DK1ADMBX with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MT31.DK1ADMBX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MT31.DK1ADMBX :
At Impexron GMBH , we offer the MT31.DK1ADMBX at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the MT31.DK1ADMBX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Vega products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Vega |
Product | MT31.DK1ADMBX |
Description | DETECTOR, WITH MOUNTING BRACKET |
Internal code | IMP4549247 |
Custom code | 90301000 |
Technical specification | MODEL: MINITRAC 31, MEASUREMENT LOOP: OHM-D-A1, REPEATABILITY: ± 0.1 % AT -40 °C TO + 60 °C (-40 °F TO +140 °F), OPERATING VOLTAGE: 20 TO 72 V DC; 20 TO 253 V AC, 50/60 HZ, MAX. POWER CONSUMPTION: 4 W; 6 VA, INPUT TYPE: 4 TO 20 MA PASSIVE, INTERNAL LOAD: 250 Ω, SWITCHING INPUT (OPEN COLLECTOR/ RELAY CONTACT): 10MA/100MA, SWITCHING VOLTAGE: MIN. 10 MV, MAX. 253 V AC, 253 V DC, SWITCHING CURRENT: MIN. 10 ΜA, MAX. 3A AC, 1A DC, BREAKING CAPACITY: MIN. 50 MW, MAX. 750 VA AC, 40 W DC, CURRENT OUTPUT RANGE: 4 TO 20 MA/HART, ACTIVE OR PASSIVE, MAX. LOAD: 500 Ω (300 Ω WITH INTRINSICALLY SAFE IS), TYPE OF OUTPUT: NPN TRANSISTOR OUTPUT (FLOATING), SWITCHING VOLTAGE: < 55 V DC, LOAD CURRENT: < 400 MA, ELECTRONICS: 4 WIRE, 4 TO 20 MA /HART (EX D OUTPUT), PROTECTION CLASS: IP66/IP67, HOUSING: ALUMINIUM DOUBLE CHAMBER, AMBIENT TEMPERATURE: -40 TO 60°C, EX CERTIFICATION: ATEX II 2 (1) G EX D [IA] IIC T6+ II 1D EX TA [IA] IIIC, END ITEM IDENTIFICATION: FOR DENSITY APPLICATIONS, ADDI. INFO. 1: TO BE SUPPLIED WITH MOUNTING BRACKET, BRACKET MODEL: PTB4.AXN, BRACKET MATERIAL: LCS W/POLYESTER POWDER COATING, BRACKET CONFIGURATION: STANDARD GAUGE MOUNTING, HARDWARE STYLE: STANDARD US THREAD, |
