Discover the superior quality and performance of the Dwyer MSX-W12-PA with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MSX-W12-PA is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MSX-W12-PA :
At Impexron GMBH , we offer the MSX-W12-PA at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the MSX-W12-PA ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Dwyer products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Dwyer |
Product | MSX-W12-PA |
Description | Differential Pressure transmitter |
Internal code | IMP4788222 |
Technical specification | Differential Pressure transmitter Serie: MSX-W12-PA (optional available with Display) Service: Air and non-combustible, compatible gases Accuracy: ±1% FSO Temperature Limits: -4 to 158°F (-20 to 70°C) Range: 1250 Pa Pressure Limits : Ranges 0 and 1: 3.6 psi max operation, 6 psi burst; Ranges 2 and 3: 6 psi max operation, 6 psi burst Power Requirement: 10-36 VDC (2-wire), 17-36 VDC or isolated 21.6-33 VAC (3-wire) Response Time: 4-20 mA (2-wire); 0-10 V or 0-5 V selectable (3-wire) Zero and Span Adjustments Digital push-button Current Consumption: 21 mA max continuous Electrical Connections: 4-wire removable European style terminal block for 16 to 26 AWG Electrical Entry / 1/2" NPS thread Process Connections 1/8", 3/16", 1/4", 5 mm, and 6 mm ID flexible tubing Enclosure Rating: NEMA 4X (IP66), UL 2043 (Plenum), UL94 V-0 Mounting Orientation Pressure sensor measurement unaffected by orientation Weight: 8.0 oz (230 g) Mounting fixture: wall mount Approvals: CE Art.-Nr.: 02-MSX-W12-PA |
