Discover the superior quality and performance of the Fischer 20820400 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 20820400 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 20820400 :
At Impexron GMBH , we offer the 20820400 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 20820400 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Fischer products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Fischer |
Product | 20820400 |
Description | Industrial control valve with driver |
Internal code | IMP4491369 |
Technical specification | Type 1124: Industrial control valve with electric drive Closing pressure: 2050 kPa BR 225 Globe Valve Type 1242A: Straight way valve BR225 Housing: Ductile iron | GGG-40.3 | EN-JS1024 Connection method: flanges according to EN 1092-2 type 21 form B1 Installation length: EN 558-1 basic series 1 nominal size: DN 25 Nominal pressure: PN 16 - 40 Kvs value: 10 m³/h Valve lift: 20 mm Characteristic curve: A-AB equal percent flow direction: counter to the closing direction Leak rate: EN 1349 - seat leakage IV L 1 (= 0.01% of the kvs value) Cone: parabolic cone made of stainless steel 1.4057 Seat: press fit made of 1.4021 Seat diameter: 25 mm Spindle sealing: O-rings made of EPDM Protective paint: L200 | 1K zinc dust primer, grey Medium: water-glycol max. temperature TS: 0... +180 °C Tech. Delivery condition: EN 1349/PED 2014/68/EU cat. I with CE mark 0045 Drive input: M10 thread for HORA MCxx3/PA-N160 /PA-N300 Type plate: with HORA logo Electric lifting actuator MC 163 Type 1922B: MC163 electric lift actuator Voltage: AE03.1| 24 V DC Actuating force: 1.12 kN Operating time: 4 s/mm Input signal: 0... 10 V DC Output signal: 0... 10 V DC Degree of protection: IP54 Electr. Connection: terminal block Drive stroke: <= 30 mm Intake: For HORA valves DN15 - DN65 | M10 | stroke 20 mm - 30 mm BR 225, BR240 S, BR240, EBR325, BR 340 S, BR340. Type plate: with HORA logo Drive equipment: AE01.1 | Way switch (2 switches) |
