Discover the superior quality and performance of the Hengesbach K-M5-00-00 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The K-M5-00-00 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of K-M5-00-00 :
At Impexron GMBH , we offer the K-M5-00-00 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the K-M5-00-00 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Hengesbach products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Hengesbach |
| Product | K-M5-00-00 |
| Description | Conductive conductivity meter |
| Internal code | IMP4885012 |
| Custom code | 90278930 |
| Technical specification | A-CONDUTEC Ordering details Process connection: Conical socket with groove nut in accordance with DIN 11851 DN 50 Option: no option --- 1. Transmitter: Polyamide housing, dimensions 100x100x60mm³, with integrated digital display Electrical connection: M20x1.5 cable screw for cable diameter 6- 12mm, protection class IP 65 in accordance with EN 60529 Measurement ranges freely programmable from 0.. 20 μS/cm to max. 0.. 500 mS/cm (see relevant technical data for the LF measuring cell) 1st output 4-20 mA, 2-wire for conductivity, galvanically isolated 2nd output 4-20 mA in 2-wire for temperature, programmable in the range T=- 40.. +160°C 2 contactless alarm outputs Supply voltage 14... 30 VDC 2. 4-electrode conductivity measurement cell Can be used for conductivities in the range of 0... 1 mS/cm to 0... 500 mS/cm. Accuracy approx. 0.02 mS/cm. Cell constant C=0.4 (C=0.5 with process connections G1 and G3) Working temperature TA = -10... +120°C. Steam sterilizable 1 h to TR = 140°C. Pressure resistance 16 max. bar Temperature measurement with integrated Pt1000 in accordance with DIN IEC 751. parts in contact with media made of PEEK, PVDF, graphite and stainless steel (weight 1.4404), EPDM sealing material with FDA. |
