Discover the superior quality and performance of the Heinrich Kübler AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A :
At Impexron GMBH , we offer the AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Heinrich Kübler products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Heinrich Kübler |
Product | AFV-S120/100-W75/50-VSSS-L143/135/08-2/V29A-1/V42A |
Description | level sensor |
Internal code | IMP4385347 |
Custom code | 85365080 |
Technical specification | Float solenoid switch FLS-MA min/max. pressure: 0.5/4 bar Min/max. temperature ፦10/150 °C Density: >900 kg/m3 Material: stainless steel 1.4404/1.4571 (316L & 316Ti) Electrical connection: aluminum housing 64x58x34 mm, Cable entry M20 x 1.5 mm/IP65 Connection flange: S120/100 Sliding tube: tube outer diameter diameter 8 mm length= 142 mm/guide tube 1 length= 135 mm/guide tube 2 Angle design: 90°, length= 75/50 mm Switching points: Switch function L1 = 49 mm normally open Switch function L2 = 79 mm normally open Switch function L3 = 117 mm normally open Float: 2x V29A, 1x V42A Float limit: adjusting ring Switching capacity: max. AC 230V; 100VA; 1A/ DC 230V; 50W; 0.5A gec. Drawing 130876 |
