Discover the superior quality and performance of the KFG Level AG KD-22487/3 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The KD-22487/3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of KD-22487/3 :
At Impexron GMBH , we offer the KD-22487/3 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the KD-22487/3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply KFG Level AG products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | KFG Level AG |
Product | KD-22487/3 |
Description | Float level switch with magnet |
Internal code | IMP4188110 |
Custom code | 90262040 |
Technical specification | FLS-CBMFZ000531000DA2ZZA7111886U ZZZZZZZZZZZZZZZZZ - KBBVJA19311NZZZ 60-AFV3 "/150/RF-VU-L1.931/12-V44A-Ex FLS-SBI type Approval: Ex i ~ KEMA 01ATEX1053 X II 1 / 2G Ex ia IIC T6 ... T1 Ga / Gb - II 2 D Ex ib IIIC T80 ° C ... T230 ° C Db Material: 316Ti stainless steel (DIN 1.4571) Pressure: 0.5 bar Temperature range: -30 ° C to 180 ° C Fluid density: 1000 kg / m³ Case: Aluminum Degree of protection: IP66 / 68 Electrical connection: M20 x 1.5 mm with cable gland Process connection: Flange ANSI B16.5 3 "150 # Form RF Switching function 1: Changeover contact (SPDT) 1886 mm Switching capacity: Ui d 36 V, Ii d 100 mA, Pi d 0,84W, Ci = 0 nF, Li = 0 mH Float: 316Ti V44A stainless steel ~ External diameter of the float: 44 mm Number of floats: 1 piece Guide tube: D.E. 12 mm Length Floating stop: Welded pin |
