Discover the superior quality and performance of the Demag KBA 100 B4 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The KBA 100 B4 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of KBA 100 B4 :
At Impexron GMBH , we offer the KBA 100 B4 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the KBA 100 B4 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Demag |
Product | KBA 100 B4 |
Description | cone runner |
Internal code | IMP5018406 |
Technical specification | The conical rotor brake motor is designed in accordance with our 203 150 44 catalog, which we will be happy to provide you with Provide The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Motor speed 1730 rpm Power 2.30 kW 100% duty cycle Motor protection class IP 55 Brake protection class IP 20 Ambient temperature -20... +40 °C Installation height ≤ 1000 m KBA 100 B 4 -B14-3 design key B14 design Terminal box layer on the left, 3 Horizontal motor installation position Total net weight approx. 27 kg Electrical data: Line voltage D/Y 280/480 V Line frequency 60 Hz D/Y current 10.60/6.20 A equipment: 3 cold conductors for shutdown at 160°C for mounting on FG10 Light cone brake disc Chrome-plated brake surfaces Brake spring ID 6997784 and 0 reducer/E Heat class F with factory certificate 2.1 in accordance with EN 10204 1x Design exactly as factory number: 50909201 Execution exactly as order number: 569467 from 2018 coloring: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive |
