Discover the superior quality and performance of the United Electric Controls J120-680-M201-1519 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The J120-680-M201-1519 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of J120-680-M201-1519 :
At Impexron GMBH , we offer the J120-680-M201-1519 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the J120-680-M201-1519 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply United Electric Controls products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | United Electric Controls |
| Product | J120-680-M201-1519 |
| Internal code | IMP4906602 |
| Custom code | 9032200000 |
| Technical specification | A00008612 Safety pressure switch 120-Series Safety pressure switch 120-Series P/N: J120-680-1519-M201 Switch point setting: internal Switch point adjustable in the range: 100.0 psi... 1700.0 psi/6.9 bar... 117.2 bar Switch point hysteresis: 9.0 psi... 40.0 psi/0.60 bar... 2.80 bar Maximum working pressure: 1700 psi/117.20 bar Maximum overpressure: 2500 psi/172.4 bar Process connection: 1/4” NPT (female) made of 316 stainless steel Sensor: 316 stainless steel bellows Notes: Not recommended for rapid or high cycling Pressure changes Housing: Die cast aluminum, epoxy powder coated; Gasketed; cover lock; internal set point lock; aluminum nameplate; protection class NEMA4X/IP66 Switch: 1 SPDT Switching capacity: see options Electrical connection: two 3/4" NPT E/C; terminal Block standard options 1519: Adjustable deadband, 15 amp 480 VAC resistive; adjustment changes rise setting only. If Adjustment of fall setting is required use primary adjustment. Left hand electrical conduction is Permanently sealed (if applicable) M201: Factory Set Single Switch; Specify Increasing or Decreasing pressure and set point XY630: distributor code Customs tariff number: 9032.20.0000 — Pressure Controls Dangerous goods for air and sea freight: No Listed for dual use: No (without guarantee) Country of origin: USA Weight (per piece): approx. 4.5 lbs./approx. 2 kg |
