Discover the superior quality and performance of the Fristam FP 3402/110 KF with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FP 3402/110 KF is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FP 3402/110 KF :
At Impexron GMBH , we offer the FP 3402/110 KF at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the FP 3402/110 KF ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Fristam products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Fristam |
Product | FP 3402/110 KF |
Description | Centrifugal pump |
Internal code | IMP4487693 |
Custom code | 84137051 |
Technical specification | Part 0406000001 Pump on KF bearing carrier Pump material: 1.4404 (316L) Shaft seal: 9.665 (2N5P2/2N5P2) 1. coal/cast chrome/NBR 2. coal/cast chrome/NBR Elastomers: NBR with FDA certification Connection type: DIN 2633 Suction side: DN 50 Pressure side: DN 40 Impeller diameter: 110 mm Engine: 0.75 kW, n = 2900 rpm 50 Hz, isoclass ISO: F Voltage: 230/400 V. IP 55 Funding data: Viscosity = 1 mPa*s — density = 1 kg/l Certificates/exams: - FDA certificate/ EC 1935/2004 engine: - Engine size IEC80 - Terminal box at the top - according to efficiency class IE3 Pumphead: - Connections: flange DIN 2633 Shaft seal: - Mechanical seal: double acting Sealing water pressure max. 0.2 bar incl. water connection with pipe G1/8" other agreements: Height to shaft centre: 180 mm Pump as S/no.: 0406 73 0082 |
