Discover the superior quality and performance of the HUBNER FG 40 K-1024G-90G-NG with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FG 40 K-1024G-90G-NG is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FG 40 K-1024G-90G-NG :
At Impexron GMBH , we offer the FG 40 K-1024G-90G-NG at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the FG 40 K-1024G-90G-NG ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply HUBNER products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | HUBNER |
Product | FG 40 K-1024G-90G-NG |
Description | Incremental Encoder with optical scanning |
Internal code | IMP4673393 |
Custom code | 9031 8080 |
Technical specification | Mechanical specification: Construction type: B 35 Dimension drawing: HM 08 M 57222a Protection class: IP 65 / Type 1 max. perm. speed: 6000 rpm Shaft DE: 11 j6 x 30 mm Electrical specification: Number of pulses: 1024 symmetrical square wave pulses basic channel 0° (A) pulse channel 90° (B) each with inverted signals error output (ERR) and inverted signals Supply voltage: 12...30 V DC (class 2) No load current: approx. 50 mA at 24 V Pulse height: HTL, approx. as supply voltage Output current: max. 150 mA at 24 V Max. frequency: 200 kHz Connection: terminal box, 10-pole spring-cage terminal strip, connection scheme PN109-400EMC cable gland Equipped with the following Options: Option N: reference pulse with inverted signal mechanically fixed Temperature range of device: -25...+85 °C (UL/CSA: -25...+70 °C) Follow-up version of ID 11841, same as delivered with S/N 401251, com. 35426 |
