Discover the superior quality and performance of the HUBNER FG4K-1024-90-N with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FG4K-1024-90-N is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FG4K-1024-90-N :
At Impexron GMBH , we offer the FG4K-1024-90-N at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the FG4K-1024-90-N ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply HUBNER products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | HUBNER |
Product | FG4K-1024-90-N |
Description | Optcal Incremental Encoder |
Internal code | IMP4670446 |
Custom code | 9031 8080 |
Technical specification | in a sturdy aluminum housing, with precision machined nickel pulse disc, 1 free shaft extension Electrical specification: number of pulses: 200 direct symmetrical square wave pulses supply voltage: 12...30 V DC rated load each output: 50 mA (Ri = 50 Ohm) max. frequency: 100 kHz special temperature range of electronics: -25 dgrs. up to +85 dgrs. Cls. with LED check output Mechanical specification: construction type: B 35 - dimension drawing HM 95 M 54006 K degree of protection: IP 55, max. perm. speed 6.000 rpm. shaft DE: 11 j6 x 30 mm connection: terminal box, 12-pole strip clamping, connection Pg 16,connection scheme EL 116 equipped with the following Options: 1. Option (90): 90 dgr. phase displacement to basic pulse 2. Option (N): marker pulse, mechanically fixed shock-proof version with sealed-in electronic card Same as delivered with S/N 401248, com. 35426. Customs tariff number 9031 8080 |
