Discover the superior quality and performance of the Fluke ESA609 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ESA609 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ESA609 :
At Impexron GMBH , we offer the ESA609 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ESA609 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Fluke products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Fluke |
| Product | ESA609 |
| Description | Electrical Safety Analyzer |
| Internal code | IMP4055119 |
| Technical specification | Range 90.0 to 264.0 V ac rms Accuracy ± (2 % of reading + 0.2 V) Earth resistance Modes Two wire Test current > 200 mA dc Range 0.000 Ω to 20.000 Ω Accuracy ± (1 % of reading + 0.010 Ω) Resistance tests Earth resistance and point to point Equipment current Mode AC RMS Range 0.0 A to 20.0 A Accuracy ± (5 % of reading + (2 counts or 0.2 A, whichever is greater)) Duty cycle 15 A to 20 A, 5 min on / 5 min off 10 A to 15 A, 7 min on / 3 min off 0 A to 10 A, continuous Leakage current Modes True-RMS Patient load selection AAMI ES1-1993 Fig. 1 IEC 60601: Fig. 15 Crest factor Less than or equal to 3 Ranges 0.0 µA to 1999.9 µA Accuracy DC to 1 kHz ± (1 % of reading + (1 µA , whichever is greater)) 1 kHz to 100 kHz ± (2.5 % of reading + (1 µA, whichever is greater)) 100 kHz to 1 MHz ± (5 % of reading + (1 µA, whichever is greater)) Leakage tests Ground wire earth Chassis (enclosure) Direct equipment Point to point Temperature Operating 0 °C to 50 °C (32 °F to 122 °F) Storage -20 °C to 60 °C (-4 °F to 140 °F) Humidity 10 % to 90 % non-condensing Altitude 120 V ac mains supply voltage 5000 m 230 V ac mains supply voltage 2000 m Display LCD display Modes of operation Manual Power ratings 115 volt power outlet 90 to 132 V ac rms, 47 to 63 Hz, 20 A maximum 230 volt power outlet 180 to 264 V ac rms, 47 to 63 Hz, 16 A maximum Power input 115 V 20 A - 2.6 kVA and 230 V at 16 A - 4.2 kVA |
