Discover the superior quality and performance of the Warex 5113.APS with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 5113.APS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 5113.APS :
At Impexron GMBH , we offer the 5113.APS at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 5113.APS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Warex |
| Product | 5113.APS |
| Internal code | IMP522040 |
| Weight | 1 |
| Technical specification | for medium : bulk chemical not aggressive, not sticky working pressure : pressureless max. allowable working pressure : < 0,5 bar (Ps) MAWP (Note: MAWP = design pressure) max. allowable working temperature: 0° C to +60° C (Ts) MAWT ambient temp.: 0° C to +50° C (Ta) Ex-protection : not required Rating of butterfly-valves according PED/2014/68/EU, diagram 7 Certified module A2 The butterfly-valves are not subject to this conformity assessment WAREX-butterfly-valve, type: DKZ 110 <APS> for mounting between flanges as per EN 1092, PN 10 body of silumin inflatable sealing-ring of NBR white replaceable, disc of stainless steel 1.4408 for DN 50 ... 350, otherwise 1.4301 shaft of stainless steel 1.4057 or equivalent bearing bush of brass test pressure: design pressure x 1,1 bar for tightness DN 100 face to face: 39 mm AT60 fitted with pneumatic actuator, type. AT 60.DR - double acting - air supply necessary: 6 bar 444ee Additional for <APS>-control ** One signal necessary * electr./pneum. control system for butterfly valves, type <APS>, for open and shut the valve and to inflate the sealing simultaneus components: 1 pce. 5/2-way solenoid valve make Norgren Herion, type. 2623077.3037 voltage: 24 V DC 2 pce. throttle-valve for solenoid-valve 2 pce. micro-switches, make. Crouzet mounted in TCR-housing 144/64/70 wired on clamps 1 pce. pneum. pressure switch make. Parker type. PWS-C5149 1 pce. mounting bracket for NAMUR solenoid-valve 1 pce. quick exhaust, type. L-SEV-1/4 MSv (from DN 350 fitted with two quick exhaust) 1 pce. pressure regulator, incl. pressure gauge 0-10 bar incl. mounting support and screwing, version according to drawing 0003475h |
