Discover the superior quality and performance of the Warex DKZ 103
The DKZ 103
Key Features of DKZ 103
At Impexron GMBH , we offer the DKZ 103
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the DKZ 103
Important Notice: While we supply Warex products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Warex |
Product | DKZ 103 <APS> DN 100 |
Description | Butterfly valve |
Internal code | IMP4690339 |
Custom code | 84818085 |
Technical specification | face to face 39 mm for mounting between flanges, drilled according to EN 1092, PN 10 body of Silumin with ground connection disc of stainless steel 1.4408 with ground connection - with enlarged gap - shaft of stainless steel stainless steel 1.4057 or equivalent shaft sealing with o-rings bearing bush of brass inflatable sealing element of NBR light blue replaceable in the housing suitable for food, correspond to European regulation (EC) No. 1935/2004 additional attachments: pneumatic actuator AT 60 DR double acting air supply necessary 6,0 bar APS control 1002 1-channel control plan 0003475 1 x quick exhaust valve 1/4", with pressure regulator Throttle silencer 1/4" brass galvanized 5/2 way solenoid-valve Norgren 2623077.3046 24 V DC, IP 65 namur interface, with manual override cat. II 3 G Ex nA IIC T5 Gc cat. II 3 D Ex tc IIIC T=95°C Dc limit switch box with 2 micro switches Crouzet 83.161.801W2 gold contacts 0,1 A, 250 V AC / 0,1 A, 24 V DC mounted in TCR-housing cover and socket of vestamid black for disc positions "open-closed" incl. mounting bracket cat. II 3 D Ex tc IIIC T80°C Dc |
