Discover the superior quality and performance of the Demag DIC-4-007-C-0000-13 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DIC-4-007-C-0000-13 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DIC-4-007-C-0000-13 :
At Impexron GMBH , we offer the DIC-4-007-C-0000-13 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the DIC-4-007-C-0000-13 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Demag |
| Product | DIC-4-007-C-0000-13 |
| Description | Frequency inverter |
| Internal code | IMP4312784 |
| Technical specification | Digital two-point inverter with voltage intermediate circuit for single and four-quadrant operation with integrated brake chopper for resistance braking. Cold plate device (separate heat sink/cooling surface required additionally); printed circuit boards with protective coating. Integrated safety function “safe torque off” (STO) according to EN 61800-5-2. Meets cat.3, PLD according to EN ISO 13849-1 and SIL2 according to IEC 61508. * Technical data: Mains voltage: 3 x 380 - 480 V (+10/-15%) Power frequency: 50/60 Hz (+10/-10%) Motorshaft power: 3.00 kW Output voltage: 3 x 0 - mains voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 7.8 A at 2 to 8kHz overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (note current reduction) Protection class: IP 20 Operating temperature: 0 - 40 °C installation height: 0 - 1000 m Dimensions: 60/250/175 mm width/height/depth Installation position: vertical Therm. Heat sink resistance: 0.31 K/W Technical data at operating point mains voltage: 3 x 400 V Output current: 7.8 A at 40°C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C installation height: 0/1000 m specification: type: Dedrive Compact STO DIC-4-007-C-0000-13 - Keypad KP 500 (programming unit) - CD-ROM 21368644 (project planning guide and other product documentation) |
