Discover the superior quality and performance of the Demag DIC-4-002-E-0000-03 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DIC-4-002-E-0000-03 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DIC-4-002-E-0000-03 :
At Impexron GMBH , we offer the DIC-4-002-E-0000-03 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the DIC-4-002-E-0000-03 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Demag |
Product | DIC-4-002-E-0000-03 |
Description | frequency converter |
Internal code | IMP4871216 |
Technical specification | Dedrive Compact STO igital two-point inverter with voltage link for one and four-quadrant operation with integrated Brake chopper for resistance braking. Integrated “Safe Torque Off” (STO) safety function in accordance with EN 61800-5-2. Fulfilled the requirements Cat.3, PLd according to EN ISO 13849-1 and SIL2 according to IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Network frequency: 50/60 Hz (+10/-10%) Motor shaft power: 0.75 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on the switching frequency Output current: 2.4 A at 2 to 8 kHz Overload factor at 2 and 4 kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (note current reduction) Protection class: IP 20 Operating temperature: 0 - 40 °C Installation height: 0 - 1000 m Dimensions: 60/190/175 mm width/height/depth Installation position: vertical Line voltage: 3 x 400 V Output current: 2.4 A at 40 °C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C Installation height: 0/1000 m specification: Type: Dedrive Compact STO DIC-4-002-E-0000-03 |
