Discover the superior quality and performance of the Demag F DH 632 H12 K V2 - 2/1 F10 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The F DH 632 H12 K V2 - 2/1 F10 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of F DH 632 H12 K V2 - 2/1 F10 :
At Impexron GMBH , we offer the F DH 632 H12 K V2 - 2/1 F10 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the F DH 632 H12 K V2 - 2/1 F10 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Demag |
| Product | F DH 632 H12 K V2 - 2/1 F10 |
| Description | rope hoist |
| Internal code | IMP4908420 |
| Technical specification | Classification to FEM in group 1AM , design to leaflet Stationary design Mounting flange position: A Rope lead-off: 1 Without control Mechanical overload device according to EC Machine Directive The hoist is designed for operation indoors at normal ambient conditions and at ambient temperatures ranging from -10°C to +40°C. Hoist unit technical data: Safe working load 6300 kg Hook path 12,00 m Wire rope 14,0 mm Main lifting: Speed 6,3 m/min Power 7,10 kW Duty factor 40 % CDF Creep lifting: Speed 0,6 m/min Power 1,500 kW Duty factor 25 % CDF Creep hoist gearbox FG08 Transmission ratio i = 10,00 Motor: Hoist motor KBH125 B 4 Creep speed motor KBA 80 B 4 Technical data electrical equipment Operating voltage 400 V Control voltage 230 V Frequency 50 Hz Current type 3-phase AC Type of enclosure motor IP 54 Operating control Without control pendant Further facilities: Geared limit switch DGS 4 Acid-resistant rope guide PA 12 Colour RAL 5009 Rope lubricant for lubrication of the rope at first commissioning Motor protection by means of embedded PTC thermistors for switching off at 160 ° C Documentation: - EU document according to the Machinery Directive Works test certificate for hook 1 fold Works test certificate for hoist 1 fold Works test certificate for wire rope 1 fold Works test certificate for engine 1 fold Test and inspection booklet |
