Discover the superior quality and performance of the Micro-Epsilon (Eltrotec) CSmi-SF15-C6/3 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CSmi-SF15-C6/3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CSmi-SF15-C6/3 :
At Impexron GMBH , we offer the CSmi-SF15-C6/3 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CSmi-SF15-C6/3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Micro-Epsilon (Eltrotec) products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Micro-Epsilon (Eltrotec) |
| Product | CSmi-SF15-C6/3 |
| Internal code | IMP4819163 |
| Technical specification | 4800523.063 Temperature range: -40 to 1030 °C Optical resolution: 15:1 Focus: 0,8 mm @ 10 mm (optional with CF-lense) Spectral range: 8 – 14 μm Response time: 14 ms – 999s (adjustable via software/ optional) Temperature resolution: 0,15 K (at object temperature >20°C and time constant >0,2s) System accuracy: ±1 % or ±1°C (whichever is greater) Repeatability: ±0,5 % or ±0,5°C (whichever is greater) Temperature coefficient: ±0,05 K/K or ±0,05 %/K Ambient temperature: -20-120 °C (sensor); -20-80 °C (controller) Storage temperature: -40°C - 85°C Power supply: 5-30 VDC Outputs: analogue: 0-5 V or 0-10 V (consumption: 9mA) Inputs: programmable functional input for external emissivity setting (0-5 VDC), Hold function, ambient temperature compensation (via USB programming interface/ optional) Emissivity: 0,100 - 1,100 adjustable via software/optional Transmissivity: 0,100 - 1,100 adjustable via software/optional Signal processing (parameter adjustable via software): peak hold, valley hold, average; extended hold function with threshold and hysteresis LED-functions: alarm indication, automatic aiming support, self diagnostic, temperature indication (via. temp. code) Environmental rating: IP65 for sensor head Scope of supply: Sensor incl. mounting nut, 6 m sensor cable, controller integrated after 3 m in connection cable, manual |
