Discover the superior quality and performance of the Technotrans cs 180e.1 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The cs 180e.1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of cs 180e.1 :
At Impexron GMBH , we offer the cs 180e.1 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the cs 180e.1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Technotrans products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Technotrans |
| Product | cs 180e.1 |
| Internal code | IMP4838160 |
| Custom code | 8419 89 98 |
| Technical specification | Key features: - Membrane keyboard with 7-segment display - LongLife stainless steel cartridge heater - Durable magnetically coupled peripheral stainless steel pump - Tankless device for minimal oxygen uptake Operating fluid, water heat transfer medium Flow temperature max. 180 °C Required water quality https://www.technotrans.de/produkte/filtrieren-und-separieren/wasserqualitaet Continuous heating via solid state semiconductor relays Heating capacity 9 kW Indirect cooling, WT 7/02 Cooling regulation solenoid valve Cooling capacity 40 kW at circulating medium temperature 130 °C at a cooling water temperature of 15 °C WP 60 MK operating pump Delivery volume max. 60 l/min Delivery pressure max. 6.0 bar Scheme BasicControl 32 bit controller ports Operating voltage 400V/50Hz/3Ph+Pe 3.0 m supply line with CEE plug 16 A Circulating medium connections forward/return G 1/2" Cooling water connections flow/return G 1/4” Cooling water pressure 3-4 bar Control cabinet protection class IP 54 Dimensions (LxWxH) 674x356x607 mm Side panels RAL 260 40 45 LED blue Case/front panel RAL 7012 basalt grey Ambient temperature max. 40 °C Volume DIN 45635T1, LpA 1m <70 dB (A) Standard equipment: Service: - Membrane keyboard with 7-segment display Heating: - “longlife” stainless steel heating cartridge Pumping technology: - Durable magnetically coupled peripheral stainless steel pump Measurement technology/ Alerting: - Electronic temperature measurement in advance - Audible and visual alarm Other equipment features: - “Tankless” device for minimal oxygen uptake - Medium-contact components made of corrosion-resistant materials - Cooling via solenoid valve - Good accessibility for maintenance work through removable cladding sheets - Interface port on the front of the device - Optimized placeability due to compact design - IP 54 control cabinet - Strainer in the coolant flow The following options are added to the standard equipment: (Options may replace standard equipment) - Profibus interface - rubber bumpers |
