Discover the superior quality and performance of the STULZ GMBH CSI 662 GES with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CSI 662 GES is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CSI 662 GES :
At Impexron GMBH , we offer the CSI 662 GES at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CSI 662 GES ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply STULZ GMBH products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | STULZ GMBH |
| Product | CSI 662 GES |
| Internal code | IMP4870971 |
| Technical specification | Additional components: - electronic expansion valve with pressure and temperature sensor in the suction line - LP low pressure switch, adjustable with automatic reset - HP high pressure switch, with manual reset - non-return valve - temperature sensor - high pressure sensor - control glass with humidity indicators control glass with humidity indicators The chiller controller is responsible for controlling the chiller and has the following connections: - Board I/O interface: EIA485 (RS485) - port for service, downloading and printing: EIA232 (RS232) - 4 sensor inputs: signal current 0 20 mA or 4 20 mA, or signal voltage 0 10 V - 11 alarm inputs: 24 V AC/DC (+ 24 V = no alarm), states displayed by LEDs - 4 analog outputs: 0 10 VDC; carrying capacity 20 mA - 7 digital outputs (relays with switching contacts), free, max 6 A, states displayed by LEDs Interface for sequential operation and remote monitoring and alarm reporting via MODBUS and SNMP protocols. Minimum cooling capacity 62 kW EER: 3.05 Refrigerant R410A Amount of coolant 8.4 kg Sound pressure level (1m free field) 59.1 dB(A) (1m) Sound power level 75.8 dB(A) Total pressure drop (chilled water) 79.8 kPa Total pressure drop (cooling water) 109.5 kPa Flow of chilled water 8.9 m³/h Flow of chilled water 15.3 m³/h Secondary circuit Glycol percentage 0 % Water inlet 18.0 °C Water outlet 12.0 °C The primary circuit of the external cooler Ethylene glycol percentage 30% Water inlet temperature 45.0 °C Water outlet temperature 50.0 °C Power supply 400V/50Hz/3Ph/N/PE Unit current consumption (OA) 40.6 A Unit energy consumption 20.8 kW 100% free cooling at an outside temperature of 10.6 °C Dimension: L x W x H (mm): 1400 x 890 x 1980 Mass: 709 kg Compressor K1 Cooling effect: 32.1 kW Condensation effect: 43.7 kW OP power consumption: 11.55 kW Compressor K2 Condensation effect: 38.9 kW OP power consumption: 8.78 kW Condensation temperature: 52.8 °C Condenser (water-cooled) K1 Power 43.1 kW Pressure drop 10.4 Pa Condenser (water-cooled) K2 Power 38.0 kW Average pressure loss 52.4 Pa Cooled water pump 1 piece Input power 1.3 kW Revolutions 2900 rev/min Efficiency 58.72 % Lifting height 8.1 m Rated input current 2.8 A |
