Discover the superior quality and performance of the Calectro CPS-D-SW with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CPS-D-SW is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CPS-D-SW :
At Impexron GMBH , we offer the CPS-D-SW at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CPS-D-SW ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Calectro products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Calectro |
Product | CPS-D-SW |
Description | differential pressure switch |
Internal code | IMP4737667 |
Technical specification | 0 3500 Pa with display The CPS-D-SW pressure switch has a built-in differential pressure element, which ensures a high accuracy and linearity are temperature-compensated. that The differential pressure element has a high resolution, which means that the pressure value is in steps of max. 1 Pa About the The entire measurement range (0 to 3500 Pa) is presented. Supply voltage: 24V AC/DC +10% Power consumption: AC 80 mA, DC 50 mA Relay output: max. load 300 mA, 60V peak Averaged attenuation: 3, 10, or 20 seconds Measuring ranges, pressure: 0-3500 Pa Set value: Adjustable from 0-3400 Pa screw clamp - Cable diameter: 0.05-1.5 mm? - Type: pull sleeve Accuracy: Usually +1% of the measured pressure (@ >100 Pa). Display: Graphic LCD, backlit Ambient temperature: -20 to +50°C Cable inputs: 1xM16, 5-10 mm cable Dimensions (WxHxD): 78x90x40 mm Protection class: IP54 |
