Discover the superior quality and performance of the BFI AUTOMATION CFC2000UV with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CFC2000UV is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CFC2000UV :
At Impexron GMBH , we offer the CFC2000UV at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CFC2000UV ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply BFI AUTOMATION products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | BFI AUTOMATION |
| Product | CFC2000UV |
| Description | Compact Flame Controller |
| Internal code | IMP3423660 |
| Weight | 1 |
| Custom code | 84169000 |
| Technical specification | 6013-2031-00 Replaces part no.: S 520.3 Dual channel compact system for continuous monitoring of gas and oil burners of any power with additional frequency analysis for a better selectivity. The compact flame controller is equipped with a semiconductor sensor whose spectral sensitivity lies in the UV range. An electronic self.monitoring ensures safe operation. Flame intensity as well as the flame relay status is indicated via LEDs. Safety switch-off time can be predefined via jumper and set by software (1-55). Sensitivity, switch ON/OFF level and switch ON delay are controlled by software. Online frequency analysing and visualisation of flame radiation is possible with the BFI software. Further technical details: Two separate and adjustable sensitivity levels Floating change-over contact for the signal flame ON/OFF. Flame relay: Ppotential-free change-over contacts max. 48V switching voltage max. 1A switching current max. 30W switching power Flame signal output: 0/4-20mA (Ra < 250 Ohm) Spectral range:2 280 to 420nm Operating mode: continuous operation Viewing angle: 2.7° Self checking: once per 800ms Supply voltage 24V DC Current consumption: approx. 200mA Ambient temperature: 20 to +70°C Data transfer via: RS232 / Infrared Interface Electrical connection: Harting-plug 90° Dimension[mm]: L 235 x W 108 x H 190 Housing: aluminum, RAL5010, IP65 ATEX-zone: II 3G Ex ec nC II T4 Gc SIL: SIL 3 |
