Discover the superior quality and performance of the BFI AUTOMATION CFC2000UV1EX with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CFC2000UV1EX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CFC2000UV1EX :
At Impexron GMBH , we offer the CFC2000UV1EX at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CFC2000UV1EX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply BFI AUTOMATION products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | BFI AUTOMATION |
| Product | CFC2000UV1EX |
| Description | Compact Flame Controller |
| Internal code | IMP4295179 |
| Custom code | 84169000 |
| Technical specification | 7013-2002-00 relay and 0/4-20mA output built-in in an ATEX zone 1 housing Dual channel compact system for continuous monitoring of gas and oil burners of any power with additional frequency analysis for a better selectivity. The compact flame controller is equipped with a semiconductor sensor whose spectral sensitivity lies in the UV range. An electronic aperture continuously controls its functioning. Flame intensity as well as the flame relay status is indicated via LEDs. Safety switch off time can be adjusted by jumper and software (1-5 s). Sensitivity, switch ON/OFF level and switch ON delay can be set by software also. An online visualisation of the flame radiation is possible by BFI software. The Compact Flame Controller is built in in a ATEX-zone 1 housing. Further technical details: Two separate and adjustable sensitivity levels Floating change-over contact for the signals Flame ON/OFF Flame relay: potential-free change-over contact max. 48V switching voltage max. 1A switching current max. 30W switching power Flame signal output: 0/4-20mA (Ra <250 Ohm) Spectral range: 190-550nm Operation mode: continuous operation Viewing angle: 2.7° Self checking: once per 800ms Supply voltage 24V DC Current consumption: approx. 200mA Ambient temperature: -20 to +70°C Data transfer via: RS232/Infrared Interface Electrical connection: 3m fixed cable Dimension [mm]: L 285 x D 120 Housing: aluminium, RAL5010, IP66 ATEX-Zone1: II 2G Ex d IIC T6 Gb II 2D Ex tb T80°C Db SIL: SIL3 |
