Discover the superior quality and performance of the BFI AUTOMATION 6013-2063-00 - CFC2000IR2-L with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 6013-2063-00 - CFC2000IR2-L is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 6013-2063-00 - CFC2000IR2-L :
At Impexron GMBH , we offer the 6013-2063-00 - CFC2000IR2-L at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 6013-2063-00 - CFC2000IR2-L ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply BFI AUTOMATION products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | BFI AUTOMATION |
| Product | 6013-2063-00 - CFC2000IR2-L |
| Description | OE converter |
| Internal code | IMP4902932 |
| Custom code | 84169000 |
| Technical specification | Relay and 0/4-20mA output Two-channel compact system for continuous monitoring of gas and oil burners of any capacity with additional frequency analysis for improved selectivity. The compact OE transducer is equipped with a semiconductor dual sensor with spectral sensitivity in the UV and IR range, which can be set separately. Electronic self-monitoring ensures safe operation. Flame intensity and the status of the flame relay are indicated by LEDs. The safety switch-off time can be predefined via a jumper and set by software (1-5s). Sensitivity, ON/OFF level and switch-on delay are set by software. Online frequency analysis and visualization of the flame radiation is possible with the BFI software. The compact flame monitor is housed in a 0E converter housing for connecting a BFI fiber optic cable (FO cable) or lance (FO lance). Further technical details: Two separate and adjustable sensitivity levels Potential-free changeover contact for the flame ON/OFF signals. Flame relay: potential-free changeover contact max. 48V switching voltage. Further technical details: Two separate and adjustable sensitivity levels Flame relay: potential-free changeover contact max. 48V switching voltage, max. 1A switching current max. 30W switching capacity, Flame signal output: 0/4-20mA (Ra <250 Ohm) Supply voltage: 24V DC Current consumption: approx. 200 mA Spectral range: 300-2700nm Viewing angle: 2.7° Self-test: once in 800ms Ambient temperature: -20 to + 70°C Data transmission: RS232/infrared interface Electrical connection: Harting plug 90° Dimension [mm]: L120xW122xH80 Housing: Aluminum, RAL5010, IP66 ATEX zone2: I 3G Ex ec nC II T4 Gc Safety Integrity Level: SIL3 |
