Discover the superior quality and performance of the TR Electronic CDH75M-00013 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CDH75M-00013 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CDH75M-00013 :
At Impexron GMBH , we offer the CDH75M-00013 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CDH75M-00013 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply TR Electronic products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | TR Electronic |
Product | CDH75M-00013 |
Internal code | IMP4832481 |
Custom code | 90318020 |
Technical specification | CDH75M-00013 Absolute encoder CDH75M*8192/32768 EPN 20H7NT +FS Total weight 1.110 kg Statistical product number: 90318020 Country of origin: GERMANY Region of origin: Baden-Württemberg AL:N ECCN:N Technical details appendix Order number description CDH75M-00013 CDH75M*8192/32768 EPN 20H7NT +FS STEP COUNT 8,192,000 REVOLUTIONS 32,768,000 PROFINET/PROFISAFE INTERFACE EN 61508 STANDARD EN 62061/EN ISO 13849 CDH75M-EPN01 SIL3/ple SAFETY INCREMENTS 4096 SIGNALS K1+K2+NEG SIGNAL LEVEL 5V SUPPLY VOLTAGE 13V.. 27V PROTECTION CLASS IP54 WORKING TEMPERATURE -20C.. +70C FLANGE TYPE GROOVE FOR PIN D4 SHAFT DESIGN 20H7/GROOVE HOLLOW SHAFT CONNECTION TYPE 1X4P.M12 PLUG 1 X 5P.M12 PLUG (SOCKET) 2X4P.M12 PLUG, D-COD (SOCKET) RADIAL CONNECTION DIRECTION MATCHING PLUG NO PIN ASSIGNMENT NUMBER TR-ECE-TI-DGB-0213 OPTION ENC IEC 61158, IEC61784-1 PRESET 1 PROFIsafe profile: No. 3.192b DRAWING NO. 04-CDH75M-M0005 DOCUMENTATION NO. DOCUMENTS AL: N ECCN: N UL APPROVALS USA+CANADA |
