Discover the superior quality and performance of the ARI 100283505-016 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 100283505-016 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 100283505-016 :
At Impexron GMBH , we offer the 100283505-016 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 100283505-016 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ARI products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | ARI |
Product | 100283505-016 |
Internal code | IMP4519589 |
Technical specification | Figure 23.470 DN 25 ARI-STEVI 470/422 Straight-through control valve with flanges and stem-guided cone EN-JS1049 DN 25 Nominal pressure: PN 16 Flange drilling: according to DIN PN16 Cone design: parabolic cone+PTFE soft seal. up to max. 200°C Kvs value: 10 Characteristic curve: equal percent Spindle sealing: roof sleeves/PTFE graphite Final acceptance test: APZ EN10204 3.1 Acceptance material testing: APZ EN10204 3.1 Drive: DP32 Supplementary product description: * DVGW-tyg-tested according to EN 13611 Additional test requirement: DIN 12266-1, leak rate A Nitrogen test medium however, 10 bar Effectively (b.pneum.antr): Spring closes in case of air failure feathery. (bar) /stroke (mm): 0.80-2.40 stroke 20 mm Erford. Setting pressure (bar): 2.7 bar max. admissible Setting pressure (bar): 6 max. closing pressure (bar): 16 Distance column length: L1=188 mm Distance column spacing: 100 mm Coupling: M10 thread Positioner: EPS 33 Input signal: 4 - 20mA 2-wire Adjusted: 4 mA valve closed Inlet with ventilation air (bar): 6 bar |
